IDD-00-045-4-B-24V

Item No.: 167.0762

Direct Illumination

IDD SERIES - Direct Dome Light Illumination

Multiple rows of LEDs are mounted inside a dome densely, allowing strong irradiation to be made by shining extreme bright light at whole angles.

Appliciation: SMD LED inspection, SMD resistor, crack and chip

Full technical specifications: Click here to download

712,00
(Price excluding VAT)
Features
Type of illumination:
Direct
Shape:
Dome
Angle:
0
Colour:
Blue
Voltage Input:
24V
Size:
45
Brand:
TMS Lite
Series:
IDD

Specification

- Color Blue

- Size 45mm

- Angle 0°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                  Current

24V / 3.60 W (Blue)       150mA

LED 470nm
