CAS2-00-020-X-W-24V

Item No.: 167.0325

Coaxial Illumination

CAS SERIES - Even coaxial light

The lights are reflected by 45 degrees half mirror to provide light in line with the camera.

Applications: surface inspection and alignment, wafer, metal surface, film, LCD and glass, pattern on PCB

Full technical specifications: Click here to download

510,00
(Price excluding VAT)
Features
Type of illumination:
Coaxial
Shape:
Coaxial
Angle:
0
Colour:
White
Voltage Input:
24V
Size:
20
Brand:
TMS Lite
Series:
CAS

Specification

- Colour White

- Size 20mm

- Angle 0°

- Continuous and Strobe Applications

- Lighting Cable 500mm

Technical Information

24V DC Input Power

Voltage/Watt                  Current

24V / 3.60 W (White)     150mA
