IDS GV-5260CP-C-HQ Rev.2.2

Item No.: 084.0011

IDS GV-5260CP-M-GL Rev.2.2, GigE Machine Vision Colour Camera

The IDS GV-5260CP-M-GL Rev.2.2 is equipped with the 2.3 MP CMOS sensor Sony IMX249 that sets new standards in terms of light sensitivity, dynamic range and color reproduction. The GigE industrial camera provides excellent image quality with extraordinarily low-noise performance - at frame rates up to 46 fps (full resolution: 1920 x 1200 px).

The sensor is perfect for applications demanding excellent image quality even in low-light conditions e.g. in ITS and in quality assurance.

This camera model is supported by IDS Vision firmware 2.20 and higher.

SKU: AB12016

Technical specifications: Click here to download

721,00
(Price excluding VAT)
Features
Colour/Mono:
Colour
Sensor Type:
SONY IMX249
Resolution:
1920x1200
Camera Type:
Matrix Camera
Megapixel:
2.3 MP
Framerate:
47 FPS
Interfaces:
GigE
IP:
IP30
Housing:
Yes
Brand:
IDS Imaging

Technical information:

- Sensor: CMOS Colour, Sony

- Sensor shutter: Global

- Sensor size: 1/1.2"

- Pixel size: 5.86 µm

- Resolution: 1920 x 1200

- Lens: C-Mount

- FPS: 47

- Power: 1.7W - 3.2W

- I/O connector: 8-pin Hirose

- Interface connector: GigE RJ45, ethernet

- IP: 30

- Operation temperature: 0 tot 55 °C

- Dimensions: 29 mm (W) x 29 mm (H) x 29mm (D)

- CE, FCC KC and RoHS compliant
